74VCXH16373 Low Voltage 16-Bit Transparent Latch with Bushold
January 2000
Revised August 2001
74VCXH16373
Low Voltage 16-Bit Transparent Latch with Bushold
General Description
The VCXH16373 contains sixteen non-inverting latches
with 3-STATE outputs and is intended for bus oriented
applications. The device is byte controlled. The flip-flops
appear to be transparent to the data when the Latch
Enable (LE) is HIGH. When LE is LOW, the data that meets
the setup time is latched. Data appears on the bus when
the Output Enable (OE) is LOW. When OE is HIGH, the
outputs are in a high impedance state.
The VCXH16373 data inputs include active bushold cir-
cuitry, eliminating the need for external pull-up resistors to
hold unused or floating data inputs at a valid logic level.
The 74VCXH16373 is designed for low voltage (1.65V to
3.6V) V
CC
applications with output compatibility up to 3.6V.
The 74VCXH16373 is fabricated with an advanced CMOS
technology to achieve high speed operation while maintain-
ing low CMOS power dissipation.
Features
s
1.65V鈥?.6V V
CC
supply operation
s
3.6V tolerant control inputs and outputs
s
Bushold on data inputs eliminates the need for external
pull-up/pull-down resistors
s
t
PD
(I
n
to O
n
)
3.0 ns max for 3.0V to 3.6V V
CC
3.4 ns max for 2.3V to 2.7V V
CC
6.8 ns max for 1.65V to 1.95V V
CC
s
Static Drive (I
OH
/I
OL
)
鹵
24 mA @ 3.0V V
CC
鹵
18 mA @ 2.3V V
CC
鹵
6 mA @ 1.65V V
CC
s
Uses patented noise/EMI reduction circuitry
s
Latch-up performance exceeds 300 mA
s
ESD performance:
Human body model
>
2000V
Machine model
>
200V
s
Also packaged in plastic Fine-Pitch Ball Grid Array
(FBGA) (Preliminary)
Ordering Code:
Order Number
74VCXH16373GX
(Note 1)
74VCXH16373MTD
(Note 2)
Package Number
BGA54A
(Preliminary)
MTD48
Package Description
54-Ball Fine-Pitch Ball Grid Array (FBGA), JEDEC MO-205, 5.5mm Wide
[TAPE and REEL]
48-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 6.1mm Wide
Note 1:
BGA package available in Tape and Reel only.
Note 2:
Devices also available in Tape and Reel. Specify by appending suffix letter 鈥淴鈥?to the ordering code.
Logic Symbol
漏 2001 Fairchild Semiconductor Corporation
DS500229
www.fairchildsemi.com
