74LVT32244 鈥?74LVTH32244 Low Voltage 32-Bit Buffer/Line Driver with 3-STATE Outputs (Preliminary)
January 2001
Revised August 2001
74LVT32244 鈥?74LVTH32244
Low Voltage 32-Bit Buffer/Line Driver
with 3-STATE Outputs (Preliminary)
General Description
The LVT32244 and LVTH32244 contain thirty-two non-
inverting buffers with 3-STATE outputs designed to be
employed as a memory and address driver, clock driver, or
bus oriented transmitter/receiver. The device is nibble con-
trolled. Individual 3-STATE control inputs can be shorted
together for 8-bit, 16-bit, or 32-bit operation.
The LVTH32244 data inputs include bushold, eliminating
the need for external pull-up resistors to hold unused
inputs.
These buffers and line drivers are designed for low-voltage
(3.3V) V
CC
applications, but with the capability to provide a
TTL interface to a 5V environment. The LVT32244 and
LVTH32244 are fabricated with an advanced BiCMOS
technology to achieve high speed operation similar to 5V
ABT while maintaining a low power dissipation
Features
s
Input and output interface capability to systems at
5V V
CC
s
Bushold data inputs eliminate the need for external
pull-up resistors to hold unused inputs (74LVTH32244),
also available without bushold feature (74LVT32244).
s
Live insertion/extraction permitted
s
Power Up/Down high impedance provides glitch-free
bus loading
s
Outputs source/sink
鈭?/div>
32 mA/
+
64 mA
s
ESD performance:
Human-body model
>
2000V
Machine model
>
200V
Charged-device model
>
1000V
s
Packaged in plastic Fine-Pitch Ball Grid Array (FBGA)
(Preliminary)
Ordering Code:
Order Number
74LVT32244GX
(Note 1)
74LVTH32244GX
(Note 1)
Package Number
BGA96A
(Preliminary)
BGA96A
(Preliminary)
Package Description
96-Ball Fine-Pitch Ball Grid Array (FBGA), JEDEC MO-205, 5.5mm Wide
[Tape and Reel]
96-Ball Fine-Pitch Ball Grid Array (FBGA), JEDEC MO-205, 5.5mm Wide
[Tape and Reel]
Note 1:
BGA package available in Tape and Reel only.
Logic Symbol
漏 2001 Fairchild Semiconductor Corporation
DS500434
www.fairchildsemi.com
