74LVT322373 鈥?74LVTH322373 Low Voltage 32-Bit Transparent Latch with 3-STATE Outputs and 25鈩?Series
鈩?/div>
Series Resistors in the Outputs
General Description
The LVT322373 and LVTH322373 contain thirty-two non-
inverting latches with 3-STATE outputs and are intended
for bus oriented applications. The device is byte controlled.
The flip-flops appear transparent to the data when the
Latch Enable (LE) is HIGH. When LE is LOW, the data that
meets the setup time is latched. Data appears on the bus
when the Output Enable (OE) is LOW. When OE is HIGH,
the outputs are in a high impedance state.
The LVTH322373 data inputs include bushold, eliminating
the need for external pull-up resistors to hold unused
inputs.
These latches are designed for low voltage (3.3V) V
CC
applications, but with the capability to provide a TTL inter-
face to a 5V environment. The LVT322373 and
LVTH322373 are fabricated with an advanced BiCMOS
technology to achieve high speed operation similar to 5V
ABT while maintaining a low power dissipation.
Features
s
Input and output interface capability to systems at
5V V
CC
s
Bushold data inputs eliminate the need for external
pull-up resistors to hold unused inputs (74LVTH322373),
also available without bushold feature (74LVT322373)
s
Live insertion/extraction permitted
s
Power Up/Down high impedance provides glitch-free
bus loading
s
Outputs include equivalent series resistance of 25
鈩?/div>
to
make external termination resistors unnecessary and
reduce overshoot and undershoot
s
ESD performance:
Human-body model
>
2000V
Machine model
>
200V
Charged-device model
>
1000V
s
Packaged in plastic Fine-Pitch Ball Grid Array (FBGA)
Ordering Code:
Order Number
74LVT322373G
(Note 1) (Note 2)
74LVTH322373G
(Note 1) (Note 2)
Package Number
BGA96A
(Preliminary)
BGA96A
Package Description
96-Ball Fine-Pitch Ball Grid Array (FBGA), JEDEC MO-205, 5.5mm Wide
96-Ball Fine-Pitch Ball Grid Array (FBGA), JEDEC MO-205, 5.5mm Wide
Note 1:
Ordering Code 鈥淕鈥?indicates Trays.
Note 2:
Devices also available in Tape and Reel. Specify by appending the suffix letter 鈥淴鈥?to the ordering code.
Logic Symbol
漏 2002 Fairchild Semiconductor Corporation
DS500742
www.fairchildsemi.com
