74LCXU04T Datasheet

  • 74LCXU04T

  • Hex Inverter

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
74LCXU04
LOW VOLTAGE CMOS HEX INVERTER
(SINGLE STAGE) WITH 5V TOLERANT INPUTS
s
s
s
s
s
s
s
s
s
s
5V TOLERANT INPUTS
HIGH SPEED:
t
PD
= 5.2 ns (MAX.) at V
CC
= 3V
POWER-DOWN PROTECTION ON INPUTS
AND OUTPUTS
SYMMETRICAL OUTPUT IMPEDANCE:
|I
OH
| = I
OL
= 24 mA (MIN)
PCI BUS LEVELS GUARANTEED AT 24mA
BALANCED PROPAGATION DELAYS:
t
PLH
鈮?/div>
t
PHL
OPERATING VOLTAGE RANGE:
V
CC
(OPR) = 2.0V to 3.6V (1.5V Data Retention)
PIN AND FUNCTION COMPATIBLE WITH
74 SERIES 04
LATCH-UP PERFORMANCE EXCEEDS 500mA
ESD PERFORMANCE:
HBM >2000V; MM > 200V
M
(Micro Package)
T
(TSSOP Package)
ORDER CODES :
74LCXU04M
74LCXU04T
technology. It is ideal for low power and high
speed 3.3V applications. it can be interfaced to
5V signal environment for inputs.
It has same speed performance at 3.3V than 5V,
AC/ACT family, combined with a lower power
consumption.
All inputs and outputs are equipped with
protection circuits against static discharge, giving
them 2KV ESD immunity and transient excess
voltage.
DESCRIPTION
The LCX04 is a low voltage CMOS HEX
INVERTER fabricated with sub-micron silicon
gate and double-layer metal wiring C
2
MOS
PIN CONNECTION AND IEC LOGIC SYMBOLS
June 2000
1/8
