74ACT574TTR Datasheet

  • 74ACT574TTR

  • Octal D-Type Flip-Flop

  • 81.23KB

  • 11頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

74ACT574
OCTAL D-TYPE FLIP-FLOP
WITH 3 STATE OUTPUTS (NON INVERTED)
s
s
s
s
s
s
s
s
s
HIGH SPEED:
f
MAX
= 270MHz (TYP.) at V
CC
= 5.0V
LOW POWER DISSIPATION:
I
CC
= 4碌A(chǔ)(MAX.) at T
A
=25擄C
COMPATIBLE WITH TTL OUTPUTS
V
IH
= 2V (MIN.), V
IL
= 0.8V (MAX.)
50鈩?TRANSMISSION LINE DRIVING
CAPABILITY
SYMMETRICAL OUTPUT IMPEDANCE:
|I
OH
| = I
OL
= 24mA (MIN)
BALANCED PROPAGATION DELAYS:
t
PLH
鈮?/div>
t
PHL
OPERATING VOLTAGE RANGE:
V
CC
(OPR) = 4.5V to 5.5V
PIN AND FUNCTION COMPATIBLE WITH
74 SERIES 574
IMPROVED LATCH-UP IMMUNITY
DIP
SOP
TSSOP
ORDER CODES
PACKAGE
DIP
SOP
TSSOP
TUBE
74ACT574B
74ACT574M
T&R
74ACT574MTR
74ACT574TTR
DESCRIPTION
The 74ACT574 is an advanced high-speed CMOS
OCTAL D-TYPE FLIP-FLOP with 3 STATE
OUTPUT NON INVERTING fabricated with
sub-micron silicon gate and double-layer metal
wiring C
2
MOS technology.
These 8 bit D-Type Flip-Flop are controlled by a
clock input (CK) and an output enable input (OE).
On the positive transition of the clock, the Q
outputs will be set to the logic that were setup at
the D inputs.
While the (OE) input is low, the 8 outputs will be in
PIN CONNECTION AND IEC LOGIC SYMBOLS
a normal logic state (high or low logic level) and
while high level the outputs will be in a high
impedance state.
The output control does not affect the internal
operation of flip-flops; that is, the old data can be
retained or the new data can be entered even
while the outputs are off.
This device is designed to interface directly High
Speed CMOS systems with TTL and NMOS
components.
All inputs and outputs are equipped with
protection circuits against static discharge, giving
them 2KV ESD immunity and transient excess
voltage.
April 2001
1/11

74ACT574TTR 產品屬性

  • 2,500

  • 集成電路 (IC)

  • 邏輯 - 觸發器

  • 74ACT

  • 標準

  • D 型總線

  • 三態非反相

  • 1

  • 8

  • 270MHz

  • 5ns

  • 正邊沿

  • 24mA，24mA

  • 4.5 V ~ 5.5 V

  • -55°C ~ 125°C

  • 表面貼裝

  • 20-TSSOP（0.173"，4.40mm 寬）

  • 帶卷 (TR)
