74ACT158MTR Datasheet

  • 74ACT158MTR

  • 2-Input Digital Multiplexer

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

74ACT158
QUAD 2 CHANNEL MULTIPLEXER (INV.)
s
s
s
s
s
s
s
s
s
HIGH SPEED: t
PD
= 6.5ns (TYP.) at V
CC
= 5V
LOW POWER DISSIPATION:
I
CC
= 4碌A(chǔ)(MAX.) at T
A
=25擄C
COMPATIBLE WITH TTL OUTPUTS
V
IH
= 2V (MIN.), V
IL
= 0.8V (MAX.)
50鈩?TRANSMISSION LINE DRIVING
CAPABILITY
SYMMETRICAL OUTPUT IMPEDANCE:
|I
OH
| = I
OL
= 24mA (MIN)
BALANCED PROPAGATION DELAYS:
t
PLH
鈮?/div>
t
PHL
OPERATING VOLTAGE RANGE:
V
CC
(OPR) = 4.5V to 5.5V
PIN AND FUNCTION COMPATIBLE WITH
74 SERIES 158
IMPROVED LATCH-UP IMMUNITY
DIP
SOP
TSSOP
ORDER CODES
PACKAGE
DIP
SOP
TSSOP
TUBE
74ACT158B
74ACT158M
T&R
74ACT158MTR
74ACT158TTR
DESCRIPTION
The 74ACT158 is an advanced high-speed CMOS
QUAD 2-CHANNEL MULTIPLEXER fabricated
with sub-micron silicon gate and double-layer
metal wiring C
2
MOS tecnology.
It consists of four 2-input digital multiplexer with
common select and strobe inputs. It is an inverting
multiplexer. When the STROBE input is held high
selection of data is inhibit and all the outputs
become high. The SELECT decoding determines
whether the A or B inputs get routed to their
corresponding Y outputs.
The device is designed to interface directly High
Speed CMOS systems with TTL, NMOS and
CMOS output voltage levels.
All inputs and outputs are equipped with
protection circuits against static discharge, giving
them 2KV ESD immunity and transient excess
voltage.
PIN CONNECTION AND IEC LOGIC SYMBOLS
April 2001
1/10

74ACT158MTR 產品屬性

  • STMicroelectronics

  • Multiplexer

  • 74AC

  • 1 / 1

  • 8.5 ns at 5 V

  • 5.5 V

  • 4.5 V

  • + 125 C

  • SMD/SMT

  • SOP-16

  • Reel

  • - 55 C

  • 1

  • 1

  • 2500
