Series D, Series HV
High Voltage Reed Relays
鈥?Normally Open or
Normally Closed Contacts
鈥?PCB or Panel
Mount Packages
The Series D Relays are PCB mount Hi
Voltage Relays capable of switching up to
8kV (dc or ac Peak). They have a dielec-
tric strength of 10kV. The DAR Series has
very low contact resistance, useful in min-
imizing errors in instrumentation systems.
The Series HV Relays are panel mount
High Voltage Reed Relays capable of
switching 10kV (dc or ac Peak) with a
dielectric strength of 12.5kV. They are
all available Normally Open or Normally
Closed and have a life expectancy of
millions of operations.
MODEL NUMBERS
FORM A (Normally OPEN)
FORM B (Normally CLOSED)
6HV1A100 12HV1A100 24HV1A100 DAR70510 DAR71210 DAT70510 DAT71210
6HV1B100 12HV1B100 24HV1B100 DBR70510 DBR71210 DBT70510 DBT71210
COIL PARAMETERS
聦
Nominal Working Voltage [Vdc]
Working Voltage Range [Vdc]
Pull-In Voltage (Contact Opens, Form B) [Vdc]
Drop Out Voltage (Contact Closes, Form B) [Vdc]
Nominal Coil Resistance [Ohms]
6
4.2-7.8
4.2
0.6
25
12
10.5-15.6
10.5
1.2
100
24
18.5-31.2
18.5
2.4
400
5
4-6
3.7
0.5
28
12
10-15
9
1.25
150
5
4-6
3.7
0.5
28
12
40-15
9
1.25
150
CONTACT PARAMETERS
聦
Maximum Switching Voltage
聧
Maximum Switching Current
聧
Maximum Contact Rating (peak)
Maximum Carry Current
Isolation Between Contacts
Contact Resistance (initial; max.)
10 kV
3A
50 W
3A
3A
12.5 kV
10 kV
3A
50 W
3A
12.5 kV
10 kV
3A
50 W
6 Adc
12.5 kV
0.1 Ohms
24 Vdc
2 Adc
25 W
5 Adc
10 kVdc
0.05 Ohms
8000 Vdc
3 Adc
50 W
15 kVdc
(10 kVdc, DBT7)
0.25 Ohms
0.1 Ohms 0.1 Ohms
RELAY PARAMETERS
聦
Operate Time (including bounce)
Release Time (including bounce)
Contact to Coil Isolation
Insulation Resistance (@ 500Vdc):
- Across Contact (typical)
- Across Contact (minimum)
- Contact to Coil (typical)
- Contact to Coil (minimum)
3 msec.
2 msec.
12.5 kV
10
13
Ohms
10
10
Ohms
10
13
Ohms
10
10
Ohms
3 msec. max (2 msec. max. DBR7/DBT7)
2 msec. max (3 msec. max. DBR7/DBT7)
>10 kVdc
10
13
Ohms
10
10
Ohms
10
13
Ohms
10
10
Ohms
漏1998 CRYDOM CORP, Specifications subject to change without notice.
GENERAL NOTES
聦
All parameters at 25潞C unless otherwise specified.
聧
Cannot exceed max. contact rating.
For recommended applications and more information contact:
USA:
(800) 8 CRYDOM
鈥?/div>
(800) 827-9366 鈥?(619) 715-7200 鈥?fax (619) 715-7280
Crydom Corp, 9525 Chesapeake Drive, San Diego, CA 92123 鈥?e-mail: sales@crydom.com
WEB SITE:
http://www.crydom.com
FASTFAX Product Information:
(888) 267-9191
UK:
(44)1202 812300
鈥?/div>
fax (44)1202 812340 Crydom International Ltd., 85, Condor Close,
Woolsbridge Industrial Estate, Three-Legged Cross. Wimborne, Dorset, England BH21 6SU
GERMANY:
(49) (0)6874 182580
鈥?/div>
fax (49)(0)6874 182585 Crydom GmbH,
Gewerbegebiet Im Schachen, D-66687 Nunkirchen, Germany 鈥?e-mail: vertrieb@crydom.com
FastFax Document No. 401
SERIES D/HV.032798, PAGE 1 OF 2
