鈥?/div>
Min
Input Current
(See Figure 1)
V
IN
= 5 Vdc
V
IN
=32 Vdc
Typ
13
13
Max Units
15
16
1.0
Vdc
mA dc
Available to DESC drawing 86031-
001 Optical isolation
Low minimum output current
Extremely low EMI
Zero voltage turn-on
Zero current turn-off
Logic compatible input
Available to Y screening levels of
MIL-R-28750
Turn-Off Voltage (Guaranteed Off)
Turn-On Voltage (Guaranteed On)
Reverse Voltage Protection
Input Voltage Range
3.8
3.8
DESCRIPTION
Vdc
-32
32
Vdc
Vdc
The 602-1 is an AC output solid state
relay designed for power switching. The
relay incorporates a hermetically sealed,
optically coupled solid state relay as a
driver. This driver provides zero voltage
turn-on as well as a logic compatible
control circuit. The relay output is rated
for 10A at 250Vac and switches the load
with a hermetically sealed triac. A built-in
snubber circuit provides reliable
switching of both resistive and reactive
loads with power factors as low as 0.2.
The internal components are potted with
a thermally conductive epoxy, which
provides an environmental seal for
severe environmental conditions
encountered in military and aerospace
applications. The 602-1 is available in W
and Y screening levels. The 602-1Y is
available to DESC drawing 86031-001
OUTPUT (LOAD) SPECIFICATIONS
Min
Output Current Rating (See Figure 3)
Output voltage Rating
Frequency Range
Output Voltage Drop @ 10 Ampere, 25
o
C
(See Figure 2)
Off-State Leakage Current
(250 Vac, 400 Hz)
Turn-On Time
Turn-Off Time
Transient Voltage
Overload Current (See Note 3)
Zero Voltage Turn-On Point
Off-State dv/dt (See Note 1)
Load Power Factor
Insulation Resistance @ 500 Vdc
Input to Output Capacitance
6/99
Typ
Max Units
10
Amps
Vac
Hz
Vrms
25
45
250
440
1.5
8.0
mA
錕?frac12;
1
Cycle
Cycle
+460 V pk
35
+15
200
0.2
10
9
15
Ohms
pF
Amps
V pk
V/us
WIRING DIAGRAM
+
+
1
CONTROL
SOURCE
2
-
-
4
3
LOAD
~
AC LINE
漏 1999 TELEDYNE RELAYS
1
2
