MILITARY DATA SHEET

MN54F821-X REV 1A0

10-BIT D-TYPE FLIP-FLOP

General Description

The F821 is a 10-bit D-type flip-flop with TRI-STATE true outputs arranged in a broadside

pinout. The F821 is functionally and pin compatible with the AMDs AM29821.

Original Creation Date: 05/10/96

Last Update Date: 07/30/96

Last Major Revision Date: 05/10/96

Industry Part Number

54F821

NS Part Numbers

54F821DMQB

54F821FMQB

54F821LMQB

Prime Die

M821

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1
