MILITARY DATA SHEET

MN54F323-X REV 1A0

Original Creation Date: 04/25/96

Last Update Date: 07/30/96

Last Major Revision Date: 04/25/96

OCTAL UNIVERSAL SHIFT/STORAGE REGISTER WITH

SYNCHRONOUS RESET AND COMMON I/O PINS

General Description

The F323 is an 8-bit universal shift/storage register with TRI-STATE outputs. Its

function is similar to the F299 with the exception of Syncronous Reset. Parallel load

inputs and flip-flop outputs are multiplexed to minimize pin count. Separate serial

inputs and outputs are provided for Q0 and Q7 to allow easy cascading. Four operation

modes are possible: hold (store), shift left, shift right and parallel load.

Industry Part Number

54F323

NS Part Numbers

54F323DMQB

54F323FMQB

54F323LMQB

Prime Die

M323

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1
