MILITARY DATA SHEET

MN54F299-X REV 1A0

Original Creation Date: 04/22/96

Last Update Date: 07/30/96

Last Major Revision Date: 04/22/96

OCTAL UNIVERSAL SHIFT/STORAGE REGISTER WITH COMMON

PARALLEL I/O PINS

General Description

The F299 is an 8-bit universal shift/storage register with TRI-STATE

of operation are possible: hold (store), shift left, shift right and

parallel load inputs and flip-flop outputs are multiplexed to reduce

package pins. Additional outputs, Q0-Q7, are provided to allow easy

separate active LOW Master Reset is used to reset the register.

outputs. Four modes

load data. The

the total number of

serial cascading. A

Industry Part Number

54F299

NS Part Numbers

54F299DM

54F299DMQB

54F299FMQB

54F299LMQB

Prime Die

M299

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1
