MICROCIRCUIT DATA SHEET

MN54ACTQ240-X REV 2A0

Original Creation Date: 07/12/96

Last Update Date: 03/19/99

Last Major Revision Date: 03/04/99

Octal Buffer/Line Driver with TRI-STATE Outputs

General Description

The ACTQ240 is an inverting octal buffer and line driver designed to be employed as

memory address driver, clock driver and bus oriented transmitter or receiver which

provides improved PC board density. The ACTQ utilizes NSC Quiet Series technology to

guarantee quiet output switching and improve dynamic threshold performance. FACT Quiet

Series TM features GTO TM output control and undershoot corrector in addition to a split

ground bus for superior performance.

Industry Part Number

54ACTQ240

NS Part Numbers

54ACTQ240DMQB*

54ACTQ240FMQB**

54ACTQ240LMQB***

Prime Die

D240

Controlling Document

5962-92184

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25 C

+125 C

-55 C

+25 C

+125 C

-55 C

+25 C

+125 C

-55 C

+25 C

+125 C

-55 C

Quality Conformance Inspection

MIL-STD-883 5005

1
