MICROCIRCUIT DATA SHEET

MN54ABT244-X REV 0B0

Original Creation Date: 09/02/94

Last Update Date: 09/24/98

Last Major Revision Date: 03/19/97

OCTAL BUFFER AND LINE DRIVER WITH TRI-STATE OUTPUTS

General Description

The ABT244 is an octal buffer and line driver with TRI-STATE outputs designed to be

employed as a memory and address driver, clock driver or bus-oriented

transmitter/receiver.

Industry Part Number

54ABT244

NS Part Numbers

54ABT244E-QML *

54ABT244E-QMLV**

54ABT244J-QML ***

54ABT244J-QMLV****

54ABT244W-QML *****

54ABT244W-QMLV******

Prime Die

NB244

Controlling Document

See Features Page

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1

next
