General Purpose Type
Photocoupler
LTV-4N35 Series/LTV-4N37 Series
4N35 Series/4N37 Series
Features
High current transfer ratio
(CTR : MIN.100% at I
F
=10mA, V
CE
=10V)
Response time
(t
on
: TYP, 3 s at V
CE
=10V, I
C
=2mA, R
L
=100 )
Input-output isolation voltage :
LTV-4N35(Viso : 3,550Vrms)
LTV-4N37(Viso : 1,550Vrms)
UL approved (No. E113898)
TUV approved (No.R9653630)
CSA approved (No. CA91533-1)
FIMKO approved (No. 193422)
NEMKO approved (No. P96103013)
DEMKO approved (No. 303985)
SEMKO approved (No. 9646047/01-30)
VDE approved (No. 094722)
Options available :
-Leads with 0.4"(10.16mm)spacing (M Type)
-Leads bends for surface mounting(S Type)
-Tape and Reel of Type I for SMD(Add"-TA"Suffix)
-Tape and Reel of Type II for SMD(Add"-TA1"Suffix)
-VDE 0884 approvals (Add"-V"Suffix)
Package Dimensions
Applications
1. I/O interfaces for computers.
2. System appliances, measuring instruments.
3. Signal transmission between circuits of different
potentials and impedances.
Ordering Information
Part Number
LTV-4N35 / 4N35
LTV-4N35M / 4N35M
LTV-4N35S / 4N35S
LTV-4N35S-TA / 4N35S-TA
LTV-4N35S-TA1 / 4N35S-TA1
LTV-4N37 / 4N37
LTV-4N37M / 4N37M
LTV-4N37S / 4N37S
LTV-4N37S-TA / 4N37S-TA
LTV-4N37S-TA1 / 4N37S-TA1
LTV4N35-V / 4N35-V
LTV4N35M-V / 4N35M-V
LTV4N35S-V / 4N35S-V
LTV4N35STA-V / 4N35STA-V
LTV4N35STA1-V / 4N35STA1-V
LTV4N37-V / 4N37-V
LTV4N37M-V / 4N37M-V
LTV4N37S-V / 4N37S-V
LTV4N37STA-V / 4N37STA-V
LTV4N37STA1-V / 4N37STA1-V
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
6-pin
Package
DIP
(leads with 0.4" spacing)
(lead bends for surface mount)
(tape and reel packaging of type
(tape and reel packaging of type
DIP
(leads with 0.4" spacing)
(lead bends for surface mount)
(tape and reel packaging of type
(tape and reel packaging of type
DIP
(leads with 0.4" spacing)
(lead bends for surface mount)
(tape and reel packaging of type
(tape and reel packaging of type
DIP
(leads with 0.4" spacing)
(lead bends for surface mount)
(tape and reel packaging of type
(tape and reel packaging of type
Safety Standard Approval
UL approved
TUV approved
CSA approved
FIMKO approved
NEMKO approved
SEMKO approved
DEMKO approved
Application part
number
LTV - 4N35
I)
II)
LTV - 4N37
I)
II)
VDE approved
LTV - 4N35
I)
II)
I)
II)
LTV - 4N37
12-33
PHOTOCOUPLER
Note:
1.Year date code.
2. 2-digit work week.
3. Factory code shall be marked (Z : Taiwan, Y : Thailand).
4. Model No.:LTV4N35 ; LTV4N37 ; 4N35 ; 4N37
5. All dimensions are in millimeters (inches).
6. Tolerance is 0.25mm (.010 ) unless otherwise noted.
7. Specifications are subject to change without notice.
1
2
3
4
