Retro-reflective Photoelectric
Sensor
50
5
25
5
脴 5.2
70
80
5.2
10
40
OCT1500-F44-
*1
-
*2
1500 mm
Features
聲 Energetic switch for standard applications
聲 1500 mm adjustable sensing range
聲 Automatic adjustment of the switch points
(sensitivity) through "TEACH IN"
聲 Visible red light
聲 Failure warning indication and output
(static, dynamic)
聲 Control / test input
聲 Programming via optical interface
(e.g. freely selectable time steps)
聲 Connector (M12x1) - adjustable
through 90擄
聲 Protection class min. IP 67
Cable sockets, mounting aids etc. see catalogue "Sensors 2"
e. g. Cable sockets: V15-G-2M-PVC (straight)
V15-W-2M-PUR (angled)
Electrical Connection
1 - Supply +
Function
Input
2 - Inverted output
or failure warning output (programmable)
3 - Supply -
4 - Switch output
5 - Multifunction input
A2
D
1
4
5
2
3
+
(Funktions-
Function
eingang)
Input
-
F000312E
09/98 01
*1 - electrical connection
*2 - mechanical connection
