IMO Series
6 Watt DC-DC Converters
Input voltage range up to 72 V DC
1 or 2 outputs up to 30 V DC
1500 V DC I/O electric strength test voltage
鈥?Wide input range
鈥?Short circuit protection
鈥?Industry standard 2" x 1" foot print
Selection chart
Output 1
U
o nom
I
o nom
[V DC] [mA]
3.3
1500
3.3
1500
5
1000
5
1000
12
500
12
500
15
400
15
400
+5
500
+5
500
+12
250
+12
250
+15
200
+15
200
Output 2
U
o nom
I
o nom
[V DC] [mA]
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
鈥?
500
鈥?
500
鈥?2
250
鈥?2
250
鈥?5
200
鈥?5
200
Input voltage
U
i
[V DC]
10...36
18...72
10...36
18...72
10...36
18...72
10...36
18...72
10...36
18...72
10...36
18...72
10...36
18...72
Rated power
T
A
= 71擄C
P
o tot
[W]
5
5
5
5
6
6
6
6
5
5
6
6
6
6
Type
Option
24 IMO 6-03-2
48 IMO 6-03-2
24 IMO 6-05-2
48 IMO 6-05-2
24 IMO 6-12-2
48 IMO 6-12-2
24 IMO 6-15-2
48 IMO 6-15-2
24 IMO 6-0505-2
48 IMO 6-0505-2
24 IMO 6-1212-2
48 IMO 6-1212-2
24 IMO 6-1515-2
48 IMO 6-1515-2
-7
-7
-7
-7
-7
-7
-7
-7
-7
-7
-7
-7
-7
-7
Input
Input voltage
Reverse voltage protection
continuous range, 24 V
continuous range, 48 V
shunt diode
10...36 V DC
18...72 V DC
Output
Output voltage setting accuracy
Minimum load
Line regulation
Load regulation
Ripple and noise
Efficiency
U
i nom
, l
o nom
not required
U
i min
...U
i max
, l
o nom
U
i nom
,
0...100%
l
o nom
,
single output models
dual output models
U
i nom
,
0...100%
l
o nom
,
peak-peak, total
U
i nom
, l
o nom
鹵2%
U
o nom
鹵1%
U
o nom
2%
U
o nom
max. 5%
U
o nom
max. 3%
U
o nom
up to 80%
Control and protection
Overload protection
No-load protection
U
i min
,
full load
150%
P
i nom
