M I C R O T U N E鈩?/div>

4736 PY5 RF T

UNER

ODULE

7713, 3

7829, 3

7909)

DVANCE

ATA

HEET

1 APPLICATIONS

ABLE

ODEM

PPLICATIONS

The 4736 PY5 RF Tuner Module is designed for subscriber-side cable modems and

digital cable applications.

Preliminary and Confidential

2 FEATURES

鈥?/div>

DOCSIS compatible

VHF Low, VHF High, and UHF

Internal tuning voltage (33V)

Single 5V power supply

All functions controlled by I

C bus

Reverse channel via pin to antenna input

Antenna input: F-connector (flat F-connector 3x7829)

Additional ESD protection provided (3x7909)

Dimensions (l x h x d): 66 x 39 x 14 mm

Optional horizontal or vertical positioning

3 INTRODUCTION

The 4736 PY5 RF Tuner Module covers a frequency range from 50 MHz to 860 MHz

for downstream signals, and 5 MHz to 42 MHz for upstream signals.

Figure 1

4736 PY5 RF Tuner Modules

The receiver uses a single-conversion approach with the reception frequency range

divided into VHF low, VHF high, and UHF.

3X 7713 ED Revision: 02

May 01

Page 1 of 15

7713ED02.doc
