403GC-3BA33C1 Datasheet

  • 403GC-3BA33C1

  • 32-Bit Microprocessor

  • 48頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PowerPC 403GC
32-Bit RISC
Embedded Controller
Features
鈥?/div>
PowerPC
鈩?/div>
RISC CPU and instruction set
architecture
鈥?/div>
Glueless interfaces to DRAM, SRAM,
ROM, and peripherals, including byte and
half-word devices
鈥?/div>
Separate instruction cache and write-back
data cache, both two-way set-associative
鈥?/div>
Memory management unit
鈥?4-entry, fully associative TLB array
鈥揤ariable page size (1KB-16MB)
鈥揊lexible TLB management
鈥?/div>
Individually programmable on-chip
controllers for:
鈥揊our DMA channels
鈥揇RAM, SRAM, and ROM banks
鈥揈xternal interrupts
鈥?/div>
Flexible interface to external bus masters
Data
Sheet
Overview
The PowerPC 403GC 32-bit RISC embedded
controller offers high performance and functional
integration with low power consumption. The
403GC RISC CPU executes at sustained speeds
approaching one cycle per instruction. On-chip
caches and integrated DRAM and SRAM control
functions reduce chip count and design
complexity in systems, while improving system
throughput.
External I/O devices or SRAM/DRAM memory
banks can be directly attached to the 403GC bus
interface unit (BIU). Interfaces for up to eight
memory banks and I/O devices, including a
maximum of four DRAM banks, can be
configured individually, allowing the BIU to
manage devices or memory banks with differing
control, timing, or bus width requirements.
鈥?/div>
Hardware multiplier and divider
鈥?/div>
Thirty-two 32-bit general purpose registers
Applications
鈥?/div>
Set-top boxes
鈥?/div>
Consumer electronics and video games
鈥?/div>
Telecommunications and networking
鈥?/div>
Office automation (printers, copiers, fax)
鈥?/div>
Personal digital assistants (PDA)
Specifications
鈥?/div>
25MHz, 33MHz, and 40MHz versions
鈥?/div>
Interfaces to both 3V and 5V technologies
鈥?/div>
Low-power 3.3V operation with built-in
power management and stand-by mode
鈥?/div>
Low-cost 160 lead PQFP package
鈥?/div>
0.5
碌
m triple-level-metal CMOS
Interrupt
Controller
JTAG
Port
Serial
Port
4-Channel
DMA
Controller
(Address
and
Control)
Timers
RISC Execution Unit
Memory Management Unit
Instruction
Cache Unit
Data
Cache Unit
On-chip
Peripheral
Bus
Bus Interface Unit
DRAM Controller
I/O Controller
Data Address
Bus Bus
DRAM
Controls
SRAM, ROM, I/O
Controls
