Alcatel 1964 TRX
SDH / SONET integrated modules
SERDES Transceiver (Transponder) STM-64 / OC-192
Description
These SERDES Transceivers are
intended to be used at 10 Gbit/s
optical SDH and SONET bit rate and
provide electrical accesses at lower
622 Mbit/s bit rate. The modules are
housed in a space-saving 300-pin
package, providing the same electrical
access for overall applications. The
transmitter side contains an in-house
cooled EA-ILM laser with a laser driver
and temperature control loop. The
transmit path starts with 16 : 1
serializer Asic. The receiver contains an
in-house III-V PIN detector with
preamplifier in a front-end module, a
main amplifier Asic, a clock and data
recovery function with accurate
decision circuit. The receive path ends
with 1 : 16 deserializer Asic. The
Alcatel 1964 TRX family is a range of
SERDES transceivers modules,
providing convenient and flexible
optical interfaces for SDH / SONET
systems operating at 9.95 Gbit/s or
10.709 Gbit/s and exceed the
applicable ITU-T G.691, Telcordia
GR-253-ed.3 and Optical Interworking
Forum OIF99.102 standards.
Features
鈥?/div>
New International Standard
鈥?/div>
Multisource Optical Interfaces
鈥?/div>
Upward compatibility with the
different features
鈥?/div>
Applications:
Short-Reach or Intra-Office (25 km)
and Intermediate-Reach or Short-
Haul (40 km)
鈥?/div>
Optical 9.95 Gbit/s rate or 10.709
Gbit/s rate (FEC)
鈥?/div>
Electrical 622 Mbit/s rate or 669
Mbit/s rate (FEC)
鈥?/div>
Operating at 1.5 碌m wavelength
鈥?/div>
Full performance in operating case
temperature from - 5 to + 65 擄C
鈥?/div>
Space-saving package : 3.5 inch x 4
inch (8.9 cm x 10.16 cm)
鈥?/div>
Alcatel Reliability and Qualification
Program for built in quality
Transmitter:
鈥?/div>
EA-ILM 1.5碌 cooled laser
鈥?/div>
Up to +2 dBm optical output
鈥?/div>
16x2 input data 622 Mbit/s LVDS
鈥?/div>
1x2 ref. clock 155 or 622 MHz PECL
compatible
鈥?/div>
Shut down command
鈥?/div>
Analog monitoring
鈥?/div>
Digital alarms
鈥?/div>
Power supplies: +5 V, - 5 V & + 3.3 V
鈥?/div>
Power consumption: 4.2 W typical
Receiver:
鈥?/div>
InGaAs PIN-preamp detector
鈥?/div>
High typical sensitivity - 15 dBm
鈥?/div>
16x2 output data 622 Mbit/s LVDS
鈥?/div>
1x2 ref. clock 155 MHz PECL
compatible
鈥?/div>
Analog monitoring
鈥?/div>
Digital alarms
鈥?/div>
Power supplies: +5 V, - 5 V & + 3.3 V
鈥?/div>
Power consumption: 2.8 W typical
Applications
Used in transmission systems from
high-speed for intermediate-reach to
long-reach applications, the
Alcatel 1900 TRX family operates at
SONET OC-192 rates as well as at
ITU-T SDH STM-64 rates. Covering all
types of SDH / SONET optical
interfaces (tributaries and aggregates)
the Alcatel 1900 TRX modules are
suitable for line systems, Add Drop
Multiplexers and digital cross-connects
as well as ATM or IP switches and
routers.
As part of the global Alcatel 1900 TRX
family, the Alcatel 1964 TRX Short-
Haul module is the first version for all
types of STM-64 (Intra-office, Short-
Haul and Long-Haul) and OC-192
(Short-Reach, Intermediate-Reach and
Long-Reach) optical interfaces. These
modules ensure ease of use and offer
new flexibility to get 10 Gbit/s optical
links to system designers.
