up to 200 mW output power
High reliability
Coolerless devices
Selected wavelengths
Wavelength stabilization with a FBG
integrated in a PMF fiber pigtail
Hermetically sealed 14-pin butterfly
package
Operating case temperature range
from 0 to 45擄C
Applications
980 nm high power pumping of
submerged Erbium Doped Fiber
Amplifiers for WDM repeaters and
branching units.
Optical Characteristics
Parameter
Output power
Forward current
Conditions
0擄 - 45擄 C
Popt = 130 mW
Popt = 150 mW
Popt = 180 mW
Popt = 200 mW
Min.
130
210
240
290
330
Typ.
240
275
330
370
Max.
200
280
320
390
430
40
2.5
984
2.5
100
Unit
mW
mA
mA
mA
mA
mA
V
nm
mA
Thresold current
Forward voltage
Wavelength
Monitor photodiode current
FIT (@ 0.95 % UCL)
Wmr = - 5 V
971.5
0.075
973, 976,
979, 982
Absolute maximum ratings
Parameter
Operating case temperature
Permanent storage temperature
Laser forward current
Laser reverse voltage
Photodiode forward current
Photodiode reverse voltage
Min
0
- 10
Max
45
+ 50
450
2.5
10
20
Unit
擄C
擄C
mA
V
mA
V
