0.9 A/W typical responsitivity
Operation at 1310 nm, 1550 nm
extended to 1620 nm wavelengths
Case operating temperature
from - 40 to + 85 擄C
3 GHz minimum bandwidth
Bit rate from 100 Mbits/s up to
2.7 Gbits/s
Low dark current
Low capacitance
Space-saving package
Alcatel Reliability and Qualification
Program for built in quality
Applications
Used in telecommunications and
datacommunication systems, from
medium to high speed for Long-Reach
and Ultra-Long-Reach applications,
Alcatel 1914 DMC modules offer a
wide case operating temperature
range from - 40 to + 85 擄C.
Part of the Alcatel 1900 DMC family,
the Alcatel 1914 DMC module is
particularly suited for all types of Long-
Haul, Metro and Access optical links
such as :
. Fiber In The Loop (FTTB, FTTC,
FTTH...)
. Digital transport links
. Private optical networks
. Intra and interoffice links
Optical characteristics
1310 nm, M = 1, P
IN
= 1 碌W
1550 nm, M = 1, P
IN
= 1 碌W
1610 nm, M = 1, P
IN
= 1 碌W
Breakdown voltage
I
D
=10碌A(chǔ)
Dark current
0,9 V
BR
, T
C
= 25 擄C
0,9 V
BR
, T
C
= 75 擄C
0,9 V
BR
, T
C
= 85 擄C
Multiplied Dark current
M = 1, T
C
= 25 擄C
M = 1, T
C
= 75 擄C
M = 1, T
C
= 85 擄C
Cut-off frequency
Note 1
Capacitance
F = 1 MHz, V
R
=3 V
Detection range
Responsitivity
Condition
Symb
位
R位
V
BR
I
D25
I
D75
I
D85
I
DM25
I
DM75
I
DM85
F
C
C
T
Min
1260
0.85
0.85
0.75
30
Typ
0.90
0.90
0.80
Max
1620
Unit
nm
A/W
V
nA
碌A(chǔ)
碌A(chǔ)
nA
nA
nA
GHz
pF
3.0
3.5
75
70
0.8
1.7
15
160
340
0.6
All parameters are specified End-of-Life within the overall relevant operating temperature range.
The typical values are referenced to + 25 擄C, nominal power supply, beginning of life.
Note 1 : M = 10, RL = 50
鈩?
- 3 dB from 500 kHz with 5 mm recommended pin length.
1
2
