3CN00217GB Datasheet

  • 3CN00217GB

  • Telecomm/Datacomm

  • 4頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Alcatel 1916 SDH
SDH / SONET integrated modules
Receiver STM-16 / OC-48 for D-WDM
Description
These integrated modules are intended
for use Dense Wavelength Division
Multiplex (D-WDM) at SDH and
SONET bit rates with a lot of noise on
the optical links with several EDFAs.
The receiver contains an in-house III-V
APD (Avalanche Photodiode) detector
with preamplifier in a front-end
module, a main amplifier ASIC, a
clock and data recovery function with
accurate decision circuit. The modules
are housed in a space-saving 30-pin
package, providing the same electrical
access for overall applications. The
Alcatel 1916 SDH family is a range of
transmitter and receiver modules,
providing convenient and flexible
optical interfaces for SDH / SONET
systems operating at 2.488 Gbit/s &
2.666 Gbit/s and exceeds the
applicable ITU-T G.957, ITU-T G.783,
ITU-T G.691 and Bellcore GR-253
standards.
Features
鈥?/div>
D-WDM receivers for Ultra-Long-
Haul :
6 400 ps/nm (320 km)
12 800 ps/nm (640 km)
鈥?/div>
Bit rate 2.488 Gbit/s & 2.666
Gbit/s (FEC)
鈥?/div>
Operate with high noise :
up to S/N = 14 dB / 0.1 nm at
2.666 Gbit/s (FEC)
up to S/N = 19 dB / 0.1 nm at 2.
488 Gbit/s
鈥?/div>
Operating 1.5 碌m wavelength
鈥?/div>
Full performance in operating case
temperature from 0 to + 70 擄C
鈥?/div>
Low power consumption
鈥?/div>
Small size less than 100 cm
2
鈥?/div>
Data Reshaping
鈥?/div>
Clock recovery & Data Retiming
鈥?/div>
Convenient digital alarms to
minimize external circuitry
鈥?/div>
Analog information for flexible
integration
鈥?/div>
Common pin-out for all modules
鈥?/div>
Alcatel Reliability and Qualification
Program for built in quality
Applications
Used in transmission systems from
medium to high-speed for
intermediate-reach to long-reach
applications, the Alcatel 1900 SDH
family operates at SONET OC-3,
OC-12 and OC-48 rates as well as at
ITU-T SDH rates of STM-1, STM-4 and
STM-16. Covering all types of
SDH / SONET optical interfaces
(tributaries and aggregates) the
Alcatel 1900 SDH modules are
suitable for line systems, Add Drop
Multiplexers and digital cross-connects
as well as ATM switches.
As part of the Alcatel 1900 SDH
family, the Alcatel 1916 SDH module
is suited for all types of STM-16 (Short-
Haul, Long-Haul, Very-Long-Haul and
Ultra-Long-Haul) and OC-48
(Intermediate-Reach, Long-Reach and
Ultra-Long-Reach) optical interfaces.
These modules ensure ease of use and
offer new flexibility to system designers.
