Symb.
K鈩?/div>
Notes : All limits start of life, Tcase = 25 擄C, Tsubmount = 25 擄C, monitor bias = - 5 V, unless otherwise stated.
[1] BER = 10
-10
; 2.488 Gbit/s modulation; 2
23
-1 PRBS; NZR line code; DER鈮?0dB
[2] 7200 ps/nm dispersion, assuming fiber with an average dispersion of 18 ps/nm/km
Absolute maximum ratings
Parameters
Min
Max
Operating case temperature
-5
70
Storage temperature
-40
85
Laser forward current
150
Laser reverse voltage
2
Modulator forward voltage
1
Modulator reverse voltage
5
Photodiode forward current
1
Photodiode reverse voltage
20
TEC Voltage
2.8
TEC Current
1.4
ESD applied on modulator
500
ESD applied on laser [1]
2000
Lead soldering time (at 260擄C)
10
Packing Mounting Screw Torque
0.2
[1] Human body model Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings only.
Unit
擄C
擄C
mA
V
V
V
mA
V
V
A
V
V
s
nm
1
2
