PremierView 15ID
15" Multimedia TFT-LCD Monitor for Industrial, OEM and Desktop Use
Calibre specialises in high performance LCD
display solutions for industrial, OEM, military
and aerospace applications. PremierView
features flexible signal capability, excellent
motion reproduction and accurate, artifact
free image re-sizing.
Calibre's PremierView 15ID is a very high
performance TFT-LCD display.
Based
around Calibre's proprietary PremierView
LCD driver technology, it is able to connect
directly to a very wide range of video or
computer image sources and display images
full screen on its 15" viewable diagonal, wide
viewing angle screen.
PremierView is one of the most flexible LCD systems on the market able to accept a wide range of input
resolutions. PremierView features true autoscanning real-time software algorithms to allow it to be
adjusted to suit most non-standard resolutions and signal timings within its resolution, line and field rate
ranges.
PremierView 15ID displays real-time Video or computer VGA-XGA full screen, full-motion in real time,
with minimal image throughput delay and no frame rate conversion. High performance scaling
algorithms work without compromising image quality or resolution irrespective of the signal resolution
implemented. It is compatible with Composite and Y/C (SVHS, S-video) inputs with automatic detection
of PAL, NTSC & SECAM video, and/or most computer RGB signals from 640x350 up to 1024x768. Very
flexible wide-ranging picture controls are provided via an on-screen menu. These controls include
picture size and position controls as well as contrast, brightness, and colour/hue for video.
A special Slow-Scan model able to accept legacy industrial graphics signals down to 15KHz interlaced
or non-interlaced is also available. Compatibility with custom signal timings and resolutions can also be
provided as a customer specific option.
PremierView 15ID uses a Samsung 1024x768 TFT-LCD panel with very wide viewing angles. All image
scaling is performed at 24-bit per RGB pixel data width, it is then converted to 18-bits using a high-
performance conversion algorithm. This ensures maximum colour depth and accurate grey-scale
reproduction, with no field merging, no field dropping or repetition and no pixel or line dropping to ensure
accurate motion reproduction and clean image scaling.
PremierView 15ID is available as a metal cased display unit or as an OEM open chassis module. The
metal cased display unit incorporates side mounting points and VESA-compatible rear mountings.
Cased units include an anti-scratch, anti-glare front viewing window. Touchscreens are also available
for all models. Optional accessories include a desk stand, wall mounts, telescopic arm mount and 19"
rackmount adapter.
