25AA040-E/ST Datasheet

  • 25AA040-E/ST

  • EEPROM

  • 323.50KB

  • 20頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

M
Part
Number
25AA040
25LC040
25C040
V
CC
Range
1.8-5.5V
2.5-5.5V
4.5-5.5V
25AA040/25LC040/25C040
DESCRIPTION
Temp.
Ranges
I
I
I,E
The Microchip Technology Inc. 25AA040/25LC040/
25C040 (25XX040
*
) is a 4 Kbit serial Electrically Eras-
able PROM. The memory is accessed via a simple
Serial Peripheral Interface鈩?(SPI鈩? compatible serial
bus. The bus signals required are a clock input (SCK)
plus separate data in (SI) and data out (SO) lines.
Access to the device is controlled through a chip select
(CS) input.
Communication to the device can be paused via the
hold pin (HOLD). While the device is paused, transi-
tions on its inputs will be ignored, with the exception of
chip select, allowing the host to service higher priority
interrupts. Also, write operations to the device can be
disabled via the write protect pin (WP).
4K SPI
鈩?/div>
Bus Serial EEPROM
DEVICE SELECTION TABLE
Max. Clock
Frequency
1 MHz
2 MHz
3 MHz
FEATURES
鈥?Low power CMOS technology
- Write current: 3 mA typical
- Read current: 500
碌A
typical
- Standby current: 500 nA typical
鈥?512 x 8-bit organization
鈥?16 byte page
鈥?Write cycle time: 5 ms max.
鈥?Self-timed ERASE and WRITE cycles
鈥?Block write protection
- Protect none, 1/4, 1/2 or all of array
鈥?Built-in write protection
- Power on/off data protection circuitry
- Write enable latch
- Write protect pin
鈥?Sequential read
鈥?High reliability
- Endurance: 1M cycles
- Data retention: > 200 years
- ESD protection: > 4000V
鈥?8-pin PDIP, SOIC, and TSSOP packages
鈥?Temperature ranges supported:
- Industrial (I):
-40擄C to +85擄C
- Automotive (E) (25C040):
-40擄C to +125擄C
BLOCK DIAGRAM
Status
Register
HV Generator
I/O Control
Logic
Memory
Control
Logic
X
Dec
EEPROM
Array
Page Latches
SI
SO
CS
SCK
HOLD
WP
V
CC
V
SS
Y Decoder
Sense Amp.
R/W Control
PACKAGE TYPES
PDIP
CS
SO
WP
V
SS
1
8
V
CC
HOLD
SCK
SI
CS
SO
WP
V
SS
1
SOIC
8
V
CC
HOLD
SCK
SI
HOLD
V
CC
CS
SO
1
TSSOP
8
SCK
SI
V
SS
WP
25XX040
25XX040
25XX040
2
3
4
7
6
5
2
3
4
7
6
5
2
3
4
7
6
5
*25XX040 is used in this document as a generic part number for the 25AA040/25LC040/25C040 devices.
SPI鈩?is a trademark of Motorola Inc.
錚?/div>
2001 Microchip Technology Inc.
DS21204C-page 1
