5 Watt HW Single Series DC/DC Converters
Selection Chart
Model
12S1R5.1200HW
12S1R8.1200HW
12S2R5.1200HW
12S3R3.1200HW
12S5.1000HW
12S12.425HW
12S15.350HW
24S1R5.1200HW
24S1R8.1200HW
24S2R5.1200HW
24S3R3.1200HW
24S5.1000HW
24S12.425HW
24S15.350HW
48S1R5.1200HW
48S1R8.1200HW
48S2R5.1200HW
48S3R3.1200HW
48S5.1000HW
48S12.425HW
48S15.350HW
Input Range
VDC
Min
Max
9
9
9
9
9
9
9
18
18
18
18
18
18
18
36
36
36
36
36
36
36
18
18
18
18
18
18
18
36
36
36
36
36
36
36
72
72
72
72
72
72
72
Output
VDC
1.5
1.8
2.5
3.3
5
12
15
1.5
1.8
2.5
3.3
5
12
15
1.5
1.8
2.5
3.3
5
12
15
Output
mA
1200
1200
1200
1200
1000
425
350
1200
1200
1200
1200
1000
425
350
1200
1200
1200
1200
1000
425
350
Features
!
!
!
!
!
!
Up to 5 Watts in 1.25" x 0.80" x 0.40" case
Efficiencies to 84%
Isolation Voltage 700 VDC
Water Washable Case Design
Overcurrent Protection for Long, Reliable Operation
Fully Self Contained,
No External Parts Required for Operation
Description
These 5 Watt DC/DC Converters were designed for fast
integration with your systems power needs. With no external
components or filtering necessary for all but the most critical
applications, these converters can provide power instantly.
This saves you costly engineering time required to design
your system around the power converter.
5 Watt Single HW Series Block Diagram
A
2401 Stanwell Drive 鈥?Concord, California 94520 鈥?Ph: 925/687-4411 or 800/542-3355 鈥?Fax: 925/687-3333 鈥?www.calex.com 鈥?Email: sales@calex.com
1
3/2001
