24AA00/24LC00/24C00
128 Bit I
2
C鈩?Bus Serial EEPROM
DEVICE SELECTION TABLE
Device
24AA00
24LC00
24C00
V
CC
Range
1.8 - 6.0
2.5 - 6.0
4.5 - 5.5
Temp Range
C,I
C,I
C,I,E
NC
3
4
Vss
PACKAGE TYPES
8-PIN PDIP/SOIC
NC
NC
1
8
V
CC
NC
SCL
SDA
24xx00
2
7
6
5
FEATURES
鈥?Low power CMOS technology
- 500
碌A(chǔ)
typical active current
- 250 nA typical standby current
鈥?Organized as 16 bytes x 8 bits
鈥?2-wire serial interface bus, I
2
C鈩?compatible
鈥?100 kHz (1.8V) and 400 kHz (5V) compatibility
鈥?Self-timed write cycle (including auto-erase)
鈥?4 ms maximum byte write cycle time
鈥?1,000,000 erase/write cycles guaranteed
鈥?ESD protection > 4 kV
鈥?Data retention > 200 years
鈥?8L DIP, SOIC, TSSOP and 5L SOT-23 packages
鈥?Temperature ranges available:
- Commercial (C):
0擄C to
+70擄C
- Industrial (I):
-40擄C to
+85擄C
- Automotive (E):
-40擄C to +125擄C
8-PIN TSSOP
NC
NC
NC
V
SS
1
2
3
4
8
7
6
5
V
CC
NC
SCL
SDA
24xx00
5-PIN SOT-23
SCL
V
SS
SDA
1
2
3
5
V
CC
24xx00
DESCRIPTION
The Microchip Technology Inc. 24AA00/24LC00/24C00
(24xx00*) is a 128-bit Electrically Erasable PROM
memory organized as 16 x 8 with a 2-wire serial inter-
face. Low voltage design permits operation down to 1.8
volts for the 24xx00 version, and every version main-
tains a maximum standby current of only 1
碌A(chǔ)
and typ-
ical active current of only 500
碌A(chǔ).
This device was
designed for where a small amount of EEPROM is
needed for the storage of calibration values, ID num-
bers or manufacturing information, etc. The 24xx00 is
available in 8-pin PDIP, 8-pin SOIC (150 mil), 8-pin
TSSOP and the 5-pin SOT-23 packages.
4
NC
BLOCK DIAGRAM
HV GENERATOR
I/O
CONTROL
LOGIC
MEMORY
CONTROL
LOGIC
XDEC
EEPROM
ARRAY
SDA
SCL
YDEC
V
CC
V
SS
SENSE AMP
R/W CONTROL
I
2
C is a trademark of Philips Corporation.
*24xx00 is used in this document as a generic part number for the 24AA00/24LC00/24C00 devices.
錚?/div>
1998 Microchip Technology Inc.
DS21178C-page 3-1
