IDC Systems

D-Subminiature

RODUCT

ESCRIPTION

Screw sets and mounting accessories are

available for all Thomas & Betts 鈥淒鈥?/div>

Connectors, facilitating any type of

installation (e.g. front panel mounting

coupling, combination of Thomas & Betts

鈥淒鈥?Connectors and standard 鈥淒鈥?/div>

connectors employing other connection

techniques).

HARDWARE FOR PLASTIC AND

METAL SHELL

鈥淒鈥?CONNECTORS, 9-37 POSITION

609-001

Screwlock Assembly

鈥?Iocks a plastic or metal shell 鈥淒鈥?/div>

connector to another rear panel

mounted plastic or metal shell 鈥淒鈥?/div>

connector

Panel thickness 3.2 (.13) mm max. Use

779-6211 retaining ring installation tool

609-002

Jackscrew Assembly

鈥?Iocks a plastic or metal shell 鈥淒鈥?/div>

connector to a jacksocket

Use 779-6210 retaining ring installation

tool

609-003

Jacksocket Assembly

鈥?Iocks a plastic or metal shell 鈥淒鈥?/div>

connector with a jackscrew to any other

front panel mounted 鈥淒鈥?connector

Panel thickness 5.0 (.196) mm max.

609-004

Jackscrew Assembly

鈥?Iocks plastic 鈥淒鈥?connectors with

backshells or metal 鈥淒鈥?connectors with

backshells with a jacksocket assembly

to any 鈥淒鈥?connector

Use 779-6210 retaining ring installation tool.

609-005

Backshell Screwlock Assembly

鈥?Iocks plastic 鈥淒鈥?connector to another

rear panel mounted plastic with 鈥淒鈥?/div>

connector with backshell

Panel thickness 3.2 (.13) mm max.

Use 779-6211 retaining ring installation

tool.

Thomas & Betts Electronics/OEM Division Tel: 901-252-5000 Fax: 901-252-1312
