T9A
series
Low Cost
30 Amp PC Board or
Panel Mount Relay
File E22575
File LR15734
Features
鈥?Up to 30 amp switching in SPST and 20 amp in SPDT arrangements.
鈥?Immersion cleanable
(6)
, plastic sealed case available.
鈥?Meets UL 873 and UL 508 spacing 鈥?1/8" through air, 1/4" over surface.
鈥?Load connections made via 1/4" Q. C. terminals and safety wells accept
insulated female Q. C. terminals (mounting codes 2 & 5).
鈥?UL Class F insulation system standard.
鈥?Well suited for various industrial, commercial and residential applications.
Initial Dielectric Strength
Between Open Contacts:
1,500V rms.
Between Contacts and Coil:
2,500V rms.
6 kV surge using 1.2碌s/50碌s Impulse Wave or
.5碌s 鈥?100kHz Ring Wave
Contact Ratings @ 25擄C
Arrangements:
1 Form A (SPST-NO), and 1 Form C (SPDT).
Material:
Silver-cadmium oxide.
Mechanical Life:
10 million operations, typical.
Minimum Contact Load:
1A @ 5VDC or 12VAC.
Initial Contact Resistance:
75 milliohms, max., @ min. rated current (switched).
Initial Insulation Resistance
Between Mutually Insulated Elements:
10
9
ohms, min., @ 500VDC,
25擄C and 50% R.H.
Contact Ratings @ 25擄C with relay properly vented. Remove vent
nib after soldering and cleaning.
Typical Electrical Load & Life - 1 Watt Coil
Contact
Arrangement
1
5
Contact Load
30A @ 240VAC
25A @ 240VAC
20A/10A @ 240VAC
20A/10A @ 240VAC
20A/10A @ 28VDC
Type of Load
UL General Purpose
Resistive Heater
UL General Purpose
UL Resistive
Resistive
Operations
100,000
100,000
100,000
100,000
100,000
Coil Data @ 25擄C
Voltage:
5 to 110VDC.
Nominal Coil Power:
1.0W, (approx.) and 900mW (approx.) versions.
Maximum Coil Power:
2.8 Watt.
Maximum Coil Temperature
(5)
: Class F:
140擄C.
Duty Cycle:
Continuous.
Coil Data - 1 Watt
Nominal
Voltage
5
9
12
18
24
48
110
DC Resistance
鹵
10% (Ohms)
25
81
144
324
576
2,304
12,100
Nominal
Current (mA)
200
111
83
56
42
21
9
Typical Electrical Load & Life - 900mW Coil
Contact
Arrangement
1
Contact Load
120VAC
120VAC
Type of Load
50 LRA/16 FLA
30 LRA/11 FLA
Operations
100,000
200,000
UL 508/873 & CSA Contact Ratings - 1 Watt Coil
Voltage
277VAC
277VAC
240VAC
240VAC
240VAC
240VAC
240VAC
125VAC
120VAC
120VAC
120VAC
28VDC
Load Type
Tungsten *
Ballast
Motor
Resistive *
General Purpose鈥?/div>
LRA/FLA **鈥犫€?/div>
Pilot Duty *
Motor
LRA/FLA
Tungsten *
Pilot Duty
Resistive
N.O. Contact
5.4A
10A
2 HP
30A
30A
80A/30A
470VA
1 HP
98A/22A
8.3A
470VA
20A
N.C. Contact
鈥?/div>
3A
1/2 HP
20A
15A
30A/12A
275VA
1/4 HP
鈥?/div>
鈥?/div>
鈥?/div>
10A
Coil Data - 900mW
Nominal
Voltage
5
9
12
18
24
48
110
DC Resistance
鹵
10% (Ohms)
27
97
155
380
660
2,560
13,450
Nominal
Current (mA)
185
93
77
47
36
19
8
Operate Data @ 25擄C
Must Operate Voltage:
75% of nominal voltage or less.
Must Release Voltage:
10% of nominal voltage or more.
Operate Time (Including Bounce)摟:
15 ms, max.
Release Time (Including Bounce)摟:
15 ms, max.
摟 At or From Nominal Coil Voltage
* Rated 6,000 operations.
** Higher UL & CSA ratings available.
鈥?For Form C application, derate current to 20A (N.O.), 10A (N.C.).
鈥犫€?For Form C application, derate current to 67%.
Note:
Consult factory for other 900mW version contact ratings.
