Model 1620
Disposable Blood Pressure Sensor
AAMI Specification
Low Cost
Multiple Configurations
Disposable Blood Pressure
Measurements
Kidney Dialysis Machines
Medical Instrumentation
DESCRIPTION
The Model 1620 is a fully piezoresistive silicon pressure sensor
for use in invasive blood pressure monitoring. The sensor is
designed to be used with automated assembly equipment and
can be dropped directly into a customer鈥檚 disposable blood
pressure housing. The sensor is designed to meet the
requirements as described in the Association for the
Advancement of Medical Instrumentation (AAMI) specification
for Blood Pressure Transducers.
The pressure sensor consists of a pressure sensing element
mounted on a ceramic substrate. Thick-film resistors on the
ceramic substrate are laser-trimmed for compensation and
calibration.
A plastic cap is attached to the ceramic substrate to provide
an easy method of attachment to the customers assembly and
FEATURES
Low Cost Disposable Design
Solid State Piezoresistive Sensor
Top Side Pressure Entry
Compatible with Automated Assembly
Equipment
Integral Dielectric Gel Barrier
Fully Tested and Compensated
protection for the sensing element. A dielectric gel is placed
over the sensor to provide electrical and fluid isolation.
The Model 1620 pressure sensors are batch manufactured
in a 10x12 element array on a ceramic substrate (120 units per
substrate). The products are shipped in anti-static shipping
containers. Performance characteristics and packaging can be
easily tailored on a special order basis to meet the requirements
of specific customers.
STANDARD RANGE
-30 to 300
mmHg
1-48
Blood Pressure
