Model 1230 UltraStable
Medical Instrumentation
PC Board Mountable Pressure Sensor
0-100 mV Output
Absolute, Differential, and Gage
Wide Temperature Range
Calibration
Process Control
Factory Automation
Air Flow Management
Leak Detection
DESCRIPTION
The Model 1230 is a high performance temperature
compensated, piezoresistive silicon pressure sensor packaged in
a dual-in-line configuration. It is intended for cost sensitive
applications where excellent performance and long-term
stability are required.
Integral temperature compensation is provided over a range
of -20擄C to +85擄C using laser-trimmed thick film resistors. An
additional laser-trimmed resistor is included to normalize
pressure sensitivity variations, for interchangeability of 鹵1%, by
programming the gain of an external differential amplifier.
Differential and gage pressure ranges from 0-15 PSI to
0-100 PSI are available. Absolute pressure ranges of 0-15 PSIA
to 0-30 PSIA are available. Multiple lead and tube
configurations are available for different applications.
FEATURES
-20擄C to +85擄C Compensated
Temperature Range
鹵0.1%
Non-linearity
鹵0.5%
Temperature Performance
1.0% Interchangeable Span
(provided by gain set resistor)
Solid State Reliability
Low Power
Please refer to the low pressure section for information on
products with operating pressures less than 0-2 PSI. For a
compensated sensor using a current set resistor as opposed to a
gain set resistor, please refer to the Model 1240.
DIMENSIONS
STANDARD RANGES
Range
0 to 15
0 to 30
0 to 50
0 to 100
psig
psid
psia
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
1-18
HITs 鈥?Wide Temperature Range
