LONG LIFE FANS
SANYO DENKI
Long Life Fan
Brushless DC Motor with Aluminium Fan Housing and Plastic Impeller
Expected Service Life of 100,000 hours (120mm fans = 200,000 hours)
(90% survival rate at 60 潞C, nominal voltage, continuous operation with
unobstructed inlets and outlets )
Permanently Lubricated Dual Ball Bearing System
Current Limiting System with Reverse Polarity Protection
Color-coded 300mm AWG 24 Leads (stripped and thinned ends)
Dual Speed Models Available
Pulse/Lock/Inverse Lock/Low Speed/Inverse Low Speed Sensor Options
Operating Temperature: -10 潞C to +60 潞C (No Condensation)
Storage Temperature: -30 潞C to +70 潞C (No Condensation)
Rotational Direction: CW looking at label (脴172mm fan = CCW)
Dielectric Strength: 50/60 Hz, 500 VAC, one (1) minute
(between lead conductor and frame)
Mass: 100g to 780g
60 x 60 x 25mm
Click on Model No in red to view air performance curves
Static
Pressure
Pa
Static
Pressure
inch/H
2
0
Nominal
Voltage
V
Voltage
Range
V
Sound
Pressure
dB(A)
Power
Input
W
Nominal
Speed
min
-1
Airflow
m
3
/min
Airflow
CFM
Model No.
0.65
0.53
0.44
0.36
0.65
0.53
0.44
0.36
0.78
0.53
23.0
18.7
15.5
12.7
23.0
18.7
15.5
12.7
27.6
18.7
57.3
40.2
29.4
19.6
57.3
40.2
29.4
19.6
87.2
40.2
0.23
0.16
0.12
0.08
0.23
0.16
0.12
0.08
0.35
0.16
12
12
12
12
24
24
24
24
48
48
10.2 - 13.8
10.2 - 13.8
10.2 - 13.8
10.2 - 13.8
20.4 - 27.6
20.4 - 27.6
20.4 - 27.6
20.4 - 27.6
40.8 - 55.2
40.8 - 53.0
33
28
24
20
33
28
24
20
39
28
2.04
1.32
1.08
0.72
1.92
1.44
1.20
0.96
3.36
1.92
4600
3800
3200
2600
4600
3800
3200
2600
5600
3800
109L0612S402
109L0612H402
109L0612F402
109L0612M402
109L0624S402
109L0624H402
109L0624F402
109L0624M402
109L0648G401*
109L0648H402
Click to view dimensional drawings
Models without sensor
Models with sensor
LONG LIFE FAN continued on next page
