100390 Low Power Single Supply Hex PECL-to-TTL Translator
September 1990
Revised August 2000
100390
Low Power Single Supply Hex PECL-to-TTL Translator
General Description
The 100390 is a hex translator for converting F100K logic
levels to TTL logic levels. Unlike other level translators, the
100390 operates using only one
+
5V supply. Differential
inputs allow each circuit to be used as an inverting, nonin-
verting, or differential receiver. An internal reference gener-
ator provides V
BB
for single-ended operation. The standard
FAST
錚?/div>
3-STATE outputs are enabled by a common active
low TTL compatible OE input. Partitioned V
CC
s on chip are
brought out on separate power pins, allowing the noisy TTL
V
CC
power plane to be isolated from the relatively quiet
ECL V
CC
. The 100390 is ideal for applications limited to a
single
+
5V supply, allowing for easy ECL to TTL Interfac-
ing.
Features
s
Operates from a single
+
5V supply
s
3-STATE outputs
s
2000V ESD protection
s
V
BB
supplied for single-ended operation
Ordering Code:
Order Number
100390SC
100390PC
100390QC
100390QI
Package Number
M24B
N24E
V28A
V28A
Package Description
24-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300 Wide
24-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-010, 0.400 Wide
28-Lead Plastic Lead Chip Carrier (PLCC), JEDEC MO-047, 0.450 Square
28-Lead Plastic Lead Chip Carrier (PLCC), JEDEC MO-047, 0.450 Square
Industrial Temperature Range (
鈭?/div>
40
擄
C to
+
85
擄
C)
Devices also available in Tape and Reel. Specify by appending the suffix letter 鈥淴鈥?to the ordering code.
Connection Diagrams
24-Pin DIP/SOIC
28-Pin PLCC
FAST錚?is a registered trademark of Fairchild Semiconductor.
漏 2000 Fairchild Semiconductor Corporation
DS010897
www.fairchildsemi.com
