100370 Low Power Universal Demultiplexer/Decoder
August 1998
100370
Low Power Universal Demultiplexer/Decoder
General Description
The 100370 universal demultiplexer/decoder functions as ei-
ther a dual 1-of-4 decoder or as a single 1-of-8 decoder, de-
pending on the signal applied to the Mode Control (M) input.
In the dual mode, each half has a pair of active-LOW Enable
(E) inputs. Pin assignments for the E inputs are such that in
the 1-of-8 mode they can easily be tied together in pairs to
provide two active-LOW enables (E
1a
to E
1b
, E
2a
to E
2b
).
Signals applied to auxiliary inputs H
a
, H
b
and H
c
determine
whether the outputs are active HIGH or active LOW. In the
dual 1-of-4 mode the Address inputs are A
0a
, A
1a
and A
0b
,
A
1b
with A
2a
unused (i.e., left open, tied to V
EE
or with LOW
signal applied). In the 1-of-8 mode, the Address inputs are
A
0a
, A
1a
, A
2a
with A
0b
and A
1b
LOW or open. All inputs have
50 k鈩?pulldown resistors.
Features
n
n
n
n
35% power reduction of the 100170
2000V ESD protection
Pin/function compatible with 100170
Voltage compensated operating range = 鈭?.2V to 鈭?.7V
Logic Symbols
Single 1-of 8 Application
Dual 1-of-4 Application
DS100311-1
DS100311-4
Pin Names
A
na
, A
nb
E
na
, E
nb
M
H
a
H
b
H
c
Z
0
鈥揨
7
Z
na
, Z
nb
Description
Address Inputs
Enable Inputs
Mode Control Input
Z
0
鈥揨
3
(Z
0a
鈥揨
3a
)
Polarity Select Input
Z
4
鈥揨
7
(Z
0b
鈥揨
3b
)
Polarity Select Input
Common Polarity
Select Input
Single 1-of-8
Data Outputs
Dual 1-of-4
Data Outputs
漏 1998 National Semiconductor Corporation
DS100311
www.national.com
