100344 Low Power 8-Bit Latch with Cut-Off Drivers
July 1988
Revised August 2000
100344
Low Power 8-Bit Latch with Cut-Off Drivers
General Description
The 100344 contains eight D-type latches, individual inputs
(D
n
), outputs (Q
n
), a common enable pin (E), latch enable
(LE), and output enable pin (OEN). A Q output follows its D
input when both E and LE are LOW. When either E or LE
(or both) are HIGH, a latch stores the last valid data
present on its D input prior to E or LE going HIGH.
A HIGH on OEN holds the outputs in a cut-off state. The
cut-off state is designed to be more negative than a normal
ECL LOW level. This allows the output emitter-followers to
turn off when the termination supply is
鈭?/div>
2.0V, presenting a
high impedance to the data bus. This high impedance
reduces termination power and prevents loss of low state
noise margin when several loads share the bus.
The 100344 outputs are designed to drive a doubly termi-
nated 50
鈩?/div>
transmission line (25
鈩?/div>
load impedance). All
inputs have 50 k
鈩?/div>
pull-down resistors.
Features
s
Cut-off drivers
s
Drives 25
鈩?/div>
load
s
Low power operation
s
2000V ESD protection
s
Voltage compensated operating range
= 鈭?/div>
4.2V to
鈭?/div>
5.7V
Ordering Code:
Order Number
100344PC
100344QC
100344QI
Package Number
N24E
V28A
V28A
Package Description
24-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-010, 0.400 Wide
28-Lead Plastic Lead Chip Carrier (PLCC), JEDEC MO-047, 0.450 Square
28-Lead Plastic Lead Chip Carrier (PLCC), JEDEC MO-047, 0.450 Square
Industrial Temperature Range (
鈭?/div>
40
擄
C to
+
85
擄
C)
Devices also available in Tape and Reel. Specify by appending the suffix letter 鈥淴鈥?to the ordering code.
Connection Diagrams
24-Pin DIP
28-Pin PLCC
Logic Symbol
漏 2000 Fairchild Semiconductor Corporation
DS009883
www.fairchildsemi.com
100344QI 產(chǎn)品屬性
Fairchild Semiconductor
1
ECL
ECL
Non-Inverting
8
- 100 mA
- 5.7 V
- 4.2 V
+ 85 C
- 40 C
PLCC-28
Rail
SMD/SMT
8
