100322 Low Power 9-Bit Buffer
October 1989
Revised August 2000
100322
Low Power 9-Bit Buffer
General Description
The 100322 is a monolithic 9-bit buffer. The device con-
tains nine non-inverting buffer gates with single input and
output. All inputs have 50 k
鈩?/div>
pull-down resistors and all
outputs are buffered.
Features
s
30% power reduction of the 100122
s
2000V ESD protection
s
Pin/function compatible with 100122
s
Voltage compensated operating range
= 鈭?/div>
4.2V to
鈭?/div>
5.7V
s
Available to MIL-STD-883
s
Available to industrial grade temperature range
(PLCC package only)
Ordering Code:
Order Number
100322PC
100322QC
100322QI
Package Number
N24E
V28A
V28A
Package Description
24-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-010, 0.400 Wide
28-Lead Plastic Lead Chip Carrier (PLCC), JEDEC MO-047, 0.450 Square
28-Lead Plastic Lead Chip Carrier (PLCC), JEDEC MO-047, 0.450 Square
Industrial Temperature Range (
鈭?/div>
40
擄
C to
+
85
擄
C)
Devices also available in Tape and Reel. Specify by appending the suffix letter 鈥淴鈥?to the ordering code.
Logic Symbol
Connection Diagrams
24-Pin DIP
Pin Descriptions
Pin Names
D
1
, D
9
O
1
, O
9
Description
Data Inputs
Data Outputs
28-Pin PLCC
Truth Table
Inputs
D
1
- D
9
L
H
H
=
HIGH Voltage Level
Outputs
O
1
- O
9
L
H
L
=
LOW Voltage Level
漏 2000 Fairchild Semiconductor Corporation
DS010608
www.fairchildsemi.com

100322QI 產品屬性

  • Fairchild Semiconductor

  • 9

  • 9

  • Non-Inverting

  • - 5.7 V

  • - 4.2 V

  • + 85 C

  • SMD/SMT

  • PLCC-28

  • Rail

  • - 50 mA

  • ECL

  • ECL

  • - 40 C

  • 9

  • 1.25 ns at - 4.2 V to - 5.7 V
