FEATURES AND SPECIFICATIONS
Features and Bene鏗乼s
s
Sizes 2 to 24 circuits
s
With or without locking ramp
Reference Information
Product Speci鏗乧ation: PS-08-50
Packaging: Bag
UL File No.: E29179
CSA File No.: LR19980
Mates With: 2220, 3190, 3192, 3243, 3246, A4042, 41661,
41662, 41671, 41672, 41681, 41682, 41701, 41711,
41721, 41741, 41761, 41771, 41772, 41791, 41792,
42441, 42461, 42471, 42491 and 42492
Use With: Molex double cantilever crimp terminals
Designed In: Inches
Electrical
Voltage: 250V
Current: 7.0A
Contact Resistance: 20m
鈩?/div>
max.
Dielectric Withstanding Voltage: 1500V
Insulation Resistance: 500K M
鈩?/div>
min.
Mechanical
Contact Insertion Force: 4 lb max.
Contact Retention to Housing: 8 lb min.
Wire Pull-Out Force: 5 lb min.
Mating Force: 24 oz max.
Unmating Force: 4 oz min.
Normal Force: 350g
Durability: 25 cycles
Physical
Housing: Nylon, UL 94V-2
Temperature: 0 to +75藲C
3.96mm (.156") Pitch
KK
廬
Wire-to-Board
Crimp Terminal Housing
3069
Polarizing Key
Polarizing Peg
Order No.
鈥?15-04-0219
鈥?15-04-0220
ORDERING INFORMATION AND DIMENSIONS
Circuits
2
3
4
5
6
7
8
9
10
11
12
13
Order No.
Without Locking
With Locking
Ramp
Ramp
09-92-0200
09-91-0200
09-92-0300
09-91-0300
09-92-0400
09-91-0400
09-92-0500
09-91-0500
09-92-0600
09-91-0600
09-92-0700
09-91-0700
09-92-0800
09-91-0800
09-92-0900
09-91-0900
09-92-1000
09-91-1000
09-92-1100
09-91-1100
09-92-1200
09-91-1200
09-92-1300
09-91-1300
Dimension
A
7.92
11.79
15.75
19.71
23.67
27.64
31.60
35.56
39.52
43.48
47.45
51.41
(.310)
(.460)
(.620)
(.780)
(.930)
(1.090)
(1.240)
(1.400)
(1.560)
(1.710)
(1.870)
(2.020)
3.96
7.92
11.89
15.85
19.81
23.77
27.74
31.70
35.66
39.62
43.59
47.55
B
(.156)
(.312)
(.468)
(.624)
(.780)
(.936)
(1.092)
(1.248)
(1.404)
(1.560)
(1.716)
(1.872)
Circuits
14
15
16
17
18
19
20
21
22
23
24
Order No.
Without Locking
With Locking
Ramp
Ramp
09-92-1400
09-91-1400
09-92-1500
09-91-1500
09-92-1600
09-91-1600
09-92-1700
09-91-1700
09-92-1800
09-91-1800
09-92-1900
09-91-1900
09-92-2000
09-91-2000
09-92-2100
09-91-2100
09-92-2200
09-91-2200
09-92-2300
09-91-2300
09-92-2400
09-91-2400
Dimension
A
55.37
59.33
63.30
67.26
71.22
65.18
79.15
83.11
87.07
91.03
95.00
(2.180)
(2.340)
(2.492)
(2.648)
(2.804)
(2.960)
(3.116)
(3.272)
(3.428)
(3.584)
(3.740)
51.51
55.47
59.44
63.40
67.36
71.32
75.29
79.25
83.21
87.17
91.14
B
(2.028)
(2.184)
(2.340)
(2.496)
(2.652)
(2.808)
(2.964)
(3.120)
(3.276)
(3.432)
(3.588)
990
J-67
PCB and Wire Connectors
