INTEGRATED CONNECTOR MODULES

10/100Base-TX belStack鈩?/div>

鈥?/div>

16-port shielded RJ-45 connector with integrated

10/100 magnetics

Compatible with a variety of 10/100 transceiver ICs

Operating temperature 0擄 to +70擄 C

Storage temperature -40擄 to +85擄 C

鈥?/div>

BM01815

Complies with IEEE standards and all 10/100 Ethernet

specifications including 350碌H with 8mA DC bias

Highly integrated design conserves valuable board space

Minimum interwinding breakdown voltage of 1500 Vrms

Adaptable, modular design provides higher reliability

鈥?/div>

ELECTRICAL SPECIFICATIONS AT 25擄 C

Common to

Differential

Mode

Rejection

dB min

60MHz to

80MHz

-12

Common to

Common

Mode

Rejection

dB min

Part Number

Insertion

Loss

dB max

Return Loss

dB min

Crosstalk

dB min

1MHz to

100MHz

0811-2X8T-18

-1.1

1MHz to

30MHz

-18

30MHz to

60MHz

18 - 20 log

(f/30MHz)

18 - 20 log

(f/30MHz)

18 - 20 log

(f/30MHz)

100kHz to 100MHz

-40

-30

-35

0811-2X8T-28

-1.1

-18

-12

-40

-30

-35

0811-2X8T-30

-1.1

-18

-12

-40

-30

-35

SCHEMATIC

0811-2X8T-18

RD+ 1

RCT 4

RD- 2

TD+ 3

TCT 7

TD- 6

1CT : 1

RJ45

1 RX+

2 RX-

3 TX+

6 TX-

75鈩?/div>

1000pF

2kV

Available Options

鈥?Various transformer turns ratios

鈥?Various high voltage capacitor values

N/C 5

Shield

漏2001 Bel Fuse Inc. Specifications subject to change without notice. 08.01

Bel Fuse Inc.

206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com

page 1
