Reduced pin count for improved crosstalk and optimum
PCB trace routing
Available Options
鈥?Various transformer turns ratios
鈥?Various LED color combinations
Adaptable, modular design provides higher reliability
Minimum interwinding breakdown voltage of 1500 Vrms
Integrated design conserves valuable board space
鈥?/div>
BM01823
Complies with IEEE 802.3 standards and all 10Base-T
Ethernet standards
ELECTRICAL SPECIFICATIONS AT 25擄 C
Insertion Loss
dB max
Part Number
1MHz to 10MHz
1MHz to 10MHz
Return Loss
dB min
Common to Common
Mode Rejection
dB min
Crosstalk
dB min
OCL
碌H min
10MHz to 30MHz
1MHz to 10MHz
0810-1X1T-12
-1.0
-15
-40
-40
200
0810-1X1T-22
-1.0
-18
-30
-35
110
SCHEMATICS
0810-1X1T-12
LED1
7
Yellow
8
TCT
1
1CT : 1.41
1
TX+
TD+ 2
TD-
3
1CT : 1
8
TCT
1
1CT : 2
1
TX+
0810-1X1T-22
RJ45
7
Yellow
RJ45
LED1
TD+ 2
TD-
3
1CT : 1
2
TX-
2
TX-
RD+ 4
RD+ 4
RD-
5
RCT 6
9
Green
10
LED2
Shield
Orange
3 RX+
4
5
6 RX-
7
8
RD-
5
3 RX+
4
5
6 RX-
7
8
RCT 6
9
Green
10
LED2
Orange
Shield
漏2001 Bel Fuse Inc.
Specifications subject to change without notice. 08.01
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
page 1
