Multilayer Ceramic Chip Capacitors Products 鈥?NPO, X7R, Y5V
HOW TO ORDER
0603
N
101
J
500
N
T
Packaging Code
T = 7鈥?reel/paper tape
Termination
N = Ag/Ni/SnPb
B = Cu/Ni/SnPb
B = Bulk
L = Ag/Ni/Sn
C = Cu/Ni/Sn
251 = 250V
501 = 500V
102 = 1000V
Voltage (VDCW)
100 = 10V
500 = 50V
160 = 16V
101 = 100V
250 = 25V
201 = 200V
APPLICATIONS
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
LC and RC tuned circuit
Filtering, Timing, & Blocking
Coupling & Bypassing
Frequency discriminating
Decoupling
Capacitance Tolerance (EIA Code)
B =
鹵0.1pF
F =
鹵1%
K =
鹵10%
C =
鹵0.25pF
G =
鹵2%
M =
鹵20%
Z = -20+80%
D =
鹵0.50pF
J =
鹵5%
Capacitance
Two significant digits followed by # of zeros
(e.g. 101 = 100pF, 102 = 1000pF, 103 = 10nF)
Dielectric
N = COG (NPO)
Size Code
0402
0805
0603
1206
B = X7R
1210
1804
F = Y5V
SCHEMATIC
L
W
T
1812
E
E
NPO
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
Ultra-stable
Low dissipation factor
Tight tolerance available
Good frequency performance
No aging of capacitance
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
X7R
Semi-stable High K
High volumetric efficiency
Highly reliable in high temp. applications
High insulation resistance
Y5V
鈭?/div>
High volumetric efficiency
鈭?/div>
Non-polar construction
鈭?/div>
General purpose, High K
DIMENSIONS
Size
Length (L)
Width (W)
Termination (E)
0402
.040鹵0.0002
1.00鹵0.05
0.020鹵0.002
0.50鹵0.05
.010+.002/-.004
0.25+0.05/-0.10
0603
0.063鹵0.004
1.60鹵0.10
0.03鹵0.004
0.80鹵0.07
0.015鹵0.006
0.40鹵0.15
0805
0.080鹵0.006
2.00鹵0.15
0.050鹵0.006
1.25鹵0.15
0.020鹵0.008
0.50鹵0.20
1206
0.125鹵0.006
3.20鹵0.15
0.063鹵0.006
1.60鹵0.15
0.025鹵0.008
0.60鹵0.20
1210
0.125鹵0.012
3.20鹵0.30
0.100鹵0.008
2.50鹵0.20
0.030鹵0.010
0.75鹵0.25
1808
0.180鹵0.015
4.50鹵0.40
0.081鹵0.010
2.03鹵0.25
0.030鹵0.010
0.75鹵0.25
1812
0.180鹵0.015
4.50鹵0.40
0.125鹵0.012
3.20鹵0.30
0.030鹵0.010
0.75鹵0.25
ELECTRICAL RATING
Dielectric
Capacitance Range
Capacitance Tolerance
Dissipation Factor
T.C.C.
Test Parameters (@25擄C)
Operating Temperature
Insulation Resistance
鈮?00pF
>1000pF
NPO (COG)
0.5pF ~ 10nF
鹵0.1pF, 鹵0.25pF, 鹵0.50pF
鹵1%, 鹵2%, 鹵5%, 鹵10%
>30pF, 0.1% Max
0鹵30ppm/擄C
1.0鹵0.2Vrms, 1MHz鹵10%
1.0鹵0.2Vrms, 1KHz鹵10%
-55 ~ +125擄C @ 25擄C
+25擄C, 10G鈩?min or 500鈩?F min,
whichever is less
X7R (BME)
100pF ~ 1碌F
鹵5%, 鹵10%, 鹵20%
6.3V:
10V & 16V:
25V & 50V:
5.0%
3.5%
2.5%
Y5V
10nF ~ 10碌F
鹵20%,
-20+80%
6.3V:
10V & 16V:
25V & 50V:
5.0%
3.5%
2.5%
0鹵15ppm/擄C
1.0鹵0.2Vrms, 1KHz鹵10%
-55 ~ +125擄C @ 25擄C
+25擄C, 10G鈩?min or 500鈩?F min,
whichever is less
+30%/-80%ppm/擄C
1.0鹵0.2Vrms, 1KHz鹵10%
-25 ~ +85擄C @ 20擄C
+25擄C, 10G鈩?min or 500鈩?F min,
whichever is less
